Concrete Canvas® (CCX®)
Concrete Canvas® (CCX®) from Global Synthetics is a revolutionary Geosynthetic Cementitious Composite Mat (GCCM). Known as "Concrete on a Roll®," CCX® provides a flexible, concrete-filled geosynthetic solution that hardens upon hydration to form a thin, durable concrete layer. This innovative material offers a fast, efficient, and sustainable alternative to conventional concrete, with reduced logistical requirements, rapid installation, and minimal environmental impact.
Product Information
Key Standard: Exceeds ASTM D8364 Type II GCCM requirements.
Thickness: 10–10.3 mm
Roll Dimensions: Up to 1.95m x 50m (95–97.5 m² per roll)
Durability: 50+ years life expectancy
Strength: Compressive strength up to 70 MPa; Flexural strength up to 10 MPa
Applications
Channel Lining
Slope Protection
Containment Solutions
Drainage Channels
Erosion Control
Mining
Benefits & Features: CCX® can be installed without plant or mixing equipment, minimising downtime and allowing for faster project completion. The LLDPE geomembrane backing significantly reduces seepage, preserving water resources and preventing structural damage.
CCX® offers superior abrasion resistance and can withstand extreme environmental conditions, ensuring long-term performance. With a unit weight of 14.5–15.5 kg/m², CCX® dramatically reduces transportation costs and environmental impact.
It delivers substantial embodied carbon savings compared to traditional concrete, supporting sustainable construction practices. Reinforced with high-tensile fibers, CCX® accommodates differential ground movement, preventing cracks and maintaining structural integrity.
Designed for longevity, CCX® ensures reliable performance for over 50 years with minimal maintenance. By maintaining low permeability, CCX® reduces water seepage losses, enhancing the efficiency of water infrastructure systems.
